This post is an extension of my ESXi setup, usually what I do after the host is up.

We will use a file to automate 100% of the configuration.

Our goal is to make this process easy, boring, and repeatable.

Prerequisites

  • ESXi 6.7 U2 Host
  • Ubuntu or similar PC

Get the vCenter ISO

Covered in an earlier post. Get the ISO any way you’d like.

Note

This demo uses: VMware-VCSA-all-6.7.0-13010631.iso

Put the ISO in your ~/Downloads folder if you plan on following my exact commands

Create the config file

First, mount the VCSA ISO locally and create a custom JSON config.

Mount the ISO

mkdir /vcsa
sudo mount -o loop ~/Downloads/VMware-VCSA-all-6.7.0-13010631.iso /vcsa

We will be using vCenter (VCSA) with an embedded PSC controller. If you’re wondering what PCS is, you can learn more about it here.

The ISO will contain a few templates for us to copy and modify. You can find VCSA and PCS’ other options here.

Copy and edit the JSON config

cp /vcsa/vcsa-cli-installer/templates/install/embedded_vCSA_on_ESXi.json /tmp/config.json

# ! OPTIONAL !
# If you want to start with my exact config:
curl -L https://gist.github.com/jimangel/8d5869a4be139e631a310e2bfe4d8b81/raw > /tmp/config.json

Validate the template without installing

/vcsa/vcsa-cli-installer/lin64/vcsa-deploy install \
--accept-eula \
--verify-template-only \
/tmp/config.json

Note

If you plan on using FQDN for the vCenter hostname, make sure the address resolves without fail. (ex: nslookup -nosearch -nodefname _FQDN_or_IP_address_)

Install VCSA to your ESXi host

Run the installation

/vcsa/vcsa-cli-installer/lin64/vcsa-deploy install \
--accept-eula \
--acknowledge-ceip \
--terse \
--no-ssl-certificate-verification \
/tmp/config.json

If you run into any issues, you can replace --terse with --verbose.

Validate vCenter install

Navigate to the vCenter FQDN_or_IP_address in your browser and log in. Don’t forget to use the proper domain.local suffix:

# The root user for VCSA is `administrator`
User: administrator@hobbyhacks.io
Password: R00tp@ssw0rd!

Conclusion

You’re now ready to deploy some VMs! The biggest reason I set up VCSA is to leverage https://github.com/vmware/govmomi, a goLang API interface to vSphere.

I plan on revisiting this post and adding in LetsEncrypt SSL certificates and VMware licenses in the config.json.

Sources:
